Ommelift 3710 RBJ

Description

The Ommelift 3710 RBJ is one of the biggest machines in the tracked, telescopic boom lift category. You can take payloads of 250 kg up to great heights, just under 37.00 m. The curve for height reach modifies automatically in relation to payload, but you can work with up to 14.20 horizontal outreach with a payload up to 80 kg. And the machine's jib-arm allows a gentle approach through the last meters to the working position.
You can remove the detachable cage for transport, reducing the machine's overall length to 7.40 m. This 5.5 tonne machine is only 1.10 m wide, but its adjustable-width tracks increase its stability on rougher terrain.
The Ommelift 3710 BDJ model has battery and diesel engine power. Both types have proportional control, which allow very supple handling, and the 220 V power supply in the cage makes your tasks even easier.
Available options include auto-setup and take-down, and remote control.

The diesel and battery bi-energy power pack makes the lift equally efficient in outdoor as in indoor environments. At outdoor operation the diesel engine is the natural choice. When working indoor the electronic motors powered by 8 high capacity batteries are the motive force. No annoying and hazardous extension cables linked to mains are needed when travelling down the indoor lanes with an amazing speed and turning strength.

The rapid 2-gear undercarriage is quickly in position and the boom system takes a 250 kg (550 lbs) basket load to maximum height in less than 3 minutes. The outreach is limited through the load moment control system at approx. 14.2 m (ft 46'6''). A 130° fly-jib facilitates working up and over obstacles and the +/-41° basket turn enables operation in narrow and awkward places.

The Omme Lift 3710 RJ is designed to traverse soft, muddy or hilly terrain but the crawler chassis is also dispersing the machine's weight of approx. 5500 kg (12,126 lbs) widely when travelling on delicate surfaces like pavements, lawns, marble or similar. Generally in connection with applications where high and extensive reach is required but low weight a necessity.

Up to 30% set-up ability provides operation on levels where self-propelled booms are unfit to work due to too steep inclines. Or maybe the self-propelled booms are just too big and just too heavy to use in the environment.

Compact dimensions allow access into tight areas. The detachable basket provides reduced length and increased manoeuvrability. The 1.50 m (ft 4'11'') width can be retracted hydraulically to only 1.10 m (ft 3'88'').
